Ultra-high frequency induction heating power supply equipment
Ultra high frequency induction heating equipment is widely used in fields such as metal processing
Classification:
Ultra-high frequency induction heating equipment
Key words:
Ultra-high frequency induction heating power supply equipment
Product Description
Ultra high frequency induction heating equipment is widely used in fields such as metal processing, welding and sintering, powder metallurgy, and heat treatment.
Ultra high frequency induction heating equipment has the following advantages:
1. Efficient heating: Ultra high frequency induction heating equipment has fast heating speed and high heating efficiency. It can quickly transfer energy to the target object without the need for preheating, greatly improving production efficiency.
2. Precise control: The ultra-high frequency induction heating equipment can precisely control the heating temperature and time according to the needs. By adjusting the frequency and power of the generator, precise control of the heating process can be achieved, ensuring the quality and stability of the product.
3. Environmental protection and energy conservation: Ultra high frequency induction heating equipment uses electrical energy for heating, without producing pollutants such as exhaust gas, wastewater, and waste residue from combustion. It has a fast heating speed, no energy loss, and can effectively save energy.
Technical parameters
| Model | Input power | Input power supply | Oscillation frequency | Cooling water pressure | Remarks |
| GCYP40 | 40KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Integrated machine |
| GCYP65 | 65KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Separate machine |
| GCYP85 | 85KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Separate machine |
| GCYP120 | 120KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Separate machine |
| GCYP160 | 160KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Separate machine |
| GCYP200 | 200KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Separate machine |
| GCYP250 | 250KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Separate machine |
| GCYP300 | 300KW | Three-phase 380v 50HZ | 15-30KHZ | 0.1-0.3MPa | Separate machine |
Service Purpose
The pursuit of value is the starting point of our work, creating value is the driving force of our life, and realizing value is our constant pursuit! To provide customers with advanced automation products and technology, in accordance with the principle of customer first, mutual benefit, to provide perfect sales and technical services.
Customer Visits
Sincerely welcome all sectors to visit, inspect, and negotiate business. Our company will rely on scientific management, high team spirit, and the wisdom of all employees to take advantage of the booming development of Shandong and work together with all sectors of society to promote the progress and development of SEG automation control technology.
Customer Service
Qualification patent
Digging deep into customer resources is the foundation of our work, and cooperation and interaction are the process of our work; cost saving, profit maximization, quality service, and advancing with the times are the focus of our work, and win-win is the result of our pursuit
recommend products
Ultra-high frequency induction heating power supply equipment
Ultra high frequency induction heating equipment is widely used in fields such as metal processing
Ultrasonic induction heating equipment GCYP36
The ultrahigh frequency induction heating equipment uses IGBT modules
Ultrasonic induction heating equipment GCYP65
The ultrahigh frequency induction heating equipment uses IGBT modules
Ultrasonic series induction heating equipment
The ultra-audio induction heating equipment adopts IGBT module, which is energy-saving and power-saving: 30% power-saving compared with electronic tube type and 20% power-saving than controlled silicon intermediate frequency.
